Information introduction
ITEM: TIMING BELT TENSIONER
PART BRAND: BRO
BRO NO.: BA1015
OUTER DIAMETER(mm) 70.6
WIDTH(mm) 25.1
MATERIAL: STEEL
DESCRIPTION
OEM NO. |
04E109479C 04E109479A 04C109479J 04C109479G 04C109479H |
REF.NO. |
INA 531 0882 10 DAYCO ATB2636 SKF VKM11338 FEBI 45795 |
LINKED VEHICLES
AUDI, A1 (8X1, 8XF) 1.4 TFSI 2012.04- 1.4l, 103kw, 140hp CPTA
AUDI, A1 (8X1, 8XF) 1.0 TFSI 2015.03- 1.0l, 70kw, 95hp CHZB
AUDI, A1 (8X1, 8XF) 1.4 TFSI 2014.11- 1.4l, 110kw, 150hp CZEA
AUDI, A1 (8X1, 8XF) 1.4 TFSI 2014.11- 1.4l, 92kw, 125hp CZCA
AUDI, A1 Sportback (8XA, 8XK) 1.4 TFSI 2012.04- 1.4l, 103kw, 140hp CPTA
AUDI, A1 Sportback (8XA, 8XK) 1.4 TFSI 2014.11- 1.4l, 110kw, 150hp CZEA
AUDI, A1 Sportback (8XA, 8XK) 1.4 TFSI 2014.11- 1.4l, 92kw, 125hp CZCA
AUDI, A1 Sportback (8XA, 8XK) 1.0 TFSI 2015.03- 1.0l, 70kw, 95hp CHZB
AUDI, A3 (8V1) 1.4 TFSI 2012.04- 1.4l, 90kw, 122hp CMBA
AUDI, A3 (8V1) 1.2 TFSI 2014.05- 1.2l, 81kw, 110hp CYVB
AUDI, A3 (8V1) 1.4 TFSI 2014.05- 1.4l, 92kw, 125hp CXSB
AUDI, A3 (8V1) 1.4 TFSI 2014.05- 1.4l, 110kw, 150hp CZEA
AUDI, A3 (8V1) 1.2 TFSI 2013.02- 1.2l, 77kw, 105hp CJZA
AUDI, A3 (8V1) 1.4 TFSI 2013.03- 1.4l, 103kw, 140hp CPTA
AUDI, A3 Convertible (8V7) 1.4 TFSI 2014.02- 1.4l, 92kw, 125hp CXSB
AUDI, A3 Convertible (8V7) 1.4 TFSI 2014.05- 1.4l, 110kw, 150hp CZEA
AUDI, A3 Convertible (8V7) 1.4 TFSI 2013.10- 1.4l, 103kw, 140hp CPTA
AUDI, A3 Limousine (8VS) 1.4 TFSI 2013.09- 1.4l, 92kw, 125hp CXSB
AUDI, A3 Limousine (8VS) 1.4 TFSI 2013.09- 1.4l, 90kw, 122hp CMBA
AUDI, A3 Limousine (8VS) 1.4 TFSI 2013.05- 1.4l, 103kw, 140hp CPTA
AUDI, A3 Limousine (8VS) 1.2 TFSI 2013.10- 1.2l, 77kw, 105hp CJZA
AUDI, A3 Limousine (8VS) 1.2 TFSI 2014.05- 1.2l, 81kw, 110hp CYVB
AUDI, A3 Limousine (8VS) 1.4 TFSI 2014.05- 1.4l, 110kw, 150hp CZEA
AUDI, A3 Sportback (8VA) 1.4 TFSI 2013.03- 1.4l, 103kw, 140hp CPTA
AUDI, A3 Sportback (8VA) 1.4 TFSI e-tron 2014.05- 1.4l, 110kw, 150hp CUKB
AUDI, A3 Sportback (8VA) 1.4 TFSI 2014.05- 1.4l, 110kw, 150hp CZEA
AUDI, A3 Sportback (8VA) 1.4 TFSI 2014.05- 1.4l, 92kw, 125hp CXSB
AUDI, A3 Sportback (8VA) 1.2 TFSI 2014.05- 1.2l, 81kw, 110hp CYVB
AUDI, A3 Sportback (8VA) 1.4 TFSI g-tron 2013.11- 1.4l, 81kw, 110hp CPWA
AUDI, A3 Sportback (8VA) 1.2 TFSI 2013.05- 1.2l, 77kw, 105hp CJZA
AUDI, A3 Sportback (8VA) 1.4 TFSI 2012.09- 1.4l, 90kw, 122hp CMBA
SEAT, IBIZA V (6J5, 6P5) 1.4 TSI 2013.10- 1.4l, 103kw, 140hp CPTA
SEAT, IBIZA V SPORTCOUPE (6J1, 6P1) 1.4 TSI 2013.10- 1.4l, 103kw, 140hp CPTA
SEAT, IBIZA V ST (6J8, 6P8) 1.4 TSI 2013.10- 1.4l, 103kw, 140hp CPTA
SEAT, LEON (5F1) 1.4 TGI 2013.02- 1.4l, 81kw, 110hp CPWA
SEAT, LEON (5F1) 1.2 TSI 2014.04- 1.2l, 81kw, 110hp CYVB
SEAT, LEON (5F1) 1.4 TSI 2014.05- 1.4l, 92kw, 125hp CZCA
SEAT, LEON (5F1) 1.4 TSI 2012.09- 1.4l, 103kw, 140hp CHPA
SEAT, LEON (5F1) 1.2 TSI 2013.01- 1.2l, 77kw, 105hp CJZA
SEAT, LEON (5F1) 1.2 TSI 2012.12- 1.2l, 63kw, 86hp CJZB
SEAT, LEON (5F1) 1.4 TSI 2014.05- 1.4l, 110kw, 150hp CZEA
SEAT, LEON (5F1) 1.4 TSI 2012.11- 1.4l, 90kw, 122hp CMBA
SEAT, LEON SC (5F5) 1.4 TSI 2013.02- 1.4l, 90kw, 122hp CMBA
SEAT, LEON SC (5F5) 1.4 TSI 2013.02- 1.4l, 103kw, 140hp CHPA
SEAT, LEON SC (5F5) 1.2 TSI 2013.02- 1.2l, 77kw, 105hp CJZA
SEAT, LEON SC (5F5) 1.4 TSI 2014.05- 1.4l, 92kw, 125hp CZCA
SEAT, LEON SC (5F5) 1.4 TSI 2014.05- 1.4l, 110kw, 150hp CZEA
SEAT, LEON SC (5F5) 1.2 TSI 2013.01- 1.2l, 63kw, 86hp CJZB
SEAT, LEON SC (5F5) 1.2 TSI 2014.05- 1.2l, 81kw, 110hp CYVB
SEAT, LEON ST (5F8) 1.4 TGI 2013.10- 1.4l, 81kw, 110hp CPWA
SEAT, LEON ST (5F8) 1.4 TSI 2014.05- 1.4l, 92kw, 125hp CZCA
SEAT, LEON ST (5F8) 1.2 TSI 2014.05- 1.2l, 81kw, 110hp CYVB
SEAT, LEON ST (5F8) 1.4 TSI 2014.05- 1.4l, 110kw, 150hp CZEA
SEAT, LEON ST (5F8) 1.4 TSI 2013.10- 1.4l, 103kw, 140hp CHPA
SEAT, LEON ST (5F8) 1.2 TSI 2013.08- 1.2l, 77kw, 105hp CJZA
SEAT, LEON ST (5F8) 1.2 TSI 2013.11- 1.2l, 63kw, 86hp CJZB
SEAT, LEON ST (5F8) 1.4 TSI 2013.10- 1.4l, 90kw, 122hp CMBA
SEAT, Mii (KF1_) 1.0 2011.10- 1.0l, 55kw, 75hp CHYB
SEAT, Mii (KF1_) 1.0 2011.10- 1.0l, 44kw, 60hp CHYA
SEAT, Mii (KF1_) 1.0 EcoFuel 2012.11- 1.0l, 50kw, 68hp CPGA
SKODA, CITIGO 1.0 2011.10- 1.0l, 55kw, 75hp CHYB
SKODA, CITIGO 1.0 CNG 2012.11- 1.0l, 50kw, 68hp CPGA
SKODA, CITIGO 1.0 2011.10- 1.0l, 44kw, 60hp CHYA
SKODA, FABIA (NJ3) 1.2 TSI 2014.08- 1.2l, 81kw, 110hp CJZD
SKODA, FABIA (NJ3) 1.0 2014.08- 1.0l, 44kw, 60hp CHYA
SKODA, FABIA (NJ3) 1.0 2014.08- 1.0l, 55kw, 75hp CHYB
SKODA, FABIA (NJ3) 1.2 TSI 2014.08- 1.2l, 66kw, 90hp CJZC
SKODA, FABIA Estate (NJ5) 1.2 TSI 2014.10- 1.2l, 81kw, 110hp CJZD
SKODA, FABIA Estate (NJ5) 1.0 2014.10- 1.0l, 44kw, 60hp CHYA
SKODA, FABIA Estate (NJ5) 1.2 TSI 2014.10- 1.2l, 66kw, 90hp CJZC
SKODA, FABIA Estate (NJ5) 1.0 2014.10- 1.0l, 55kw, 75hp CHYB
SKODA, OCTAVIA (5E3) 1.2 TSI 2012.11- 1.2l, 63kw, 86hp CJZB
SKODA, OCTAVIA (5E3) 1.2 TSI 2012.11- 1.2l, 77kw, 105hp CJZA
SKODA, OCTAVIA (5E3) 1.4 TSI G-TEC 2013.11- 1.4l, 81kw, 110hp CPWA
SKODA, OCTAVIA (5E3) 1.4 TSI 2012.11- 1.4l, 103kw, 140hp CHPA
SKODA, OCTAVIA Combi (5E5) 1.4 TSI G-TEC 2013.11- 1.4l, 81kw, 110hp CPWA
SKODA, OCTAVIA Combi (5E5) 1.4 TSI 2012.11- 1.4l, 103kw, 140hp CHPA
SKODA, OCTAVIA Combi (5E5) 1.2 TSI 2012.11- 1.2l, 77kw, 105hp CJZA
SKODA, OCTAVIA Combi (5E5) 1.2 TSI 2012.11- 1.2l, 63kw, 86hp CJZB
VW, BEETLE (5C1) 1.4 TSI 2014.12- 1.4l, 110kw, 150hp CZDA
VW, GOLF SPORTSVAN (AM1) 1.4 TSI 2014.04- 1.4l, 92kw, 125hp CPVB
VW, GOLF SPORTSVAN (AM1) 1.2 TSI 2014.04- 1.2l, 81kw, 110hp CYVB
VW, GOLF SPORTSVAN (AM1) 1.4 TSI 2014.02- 1.4l, 110kw, 150hp CZDA
VW, GOLF SPORTSVAN (AM1) 1.4 TSI MultiFuel 2014.04- 1.4l, 92kw, 125hp CPVB
VW, GOLF SPORTSVAN (AM1) 1.6 2014.05- 1.6l, 81kw, 110hp CWVA
VW, GOLF SPORTSVAN (AM1) 1.2 TSI 2014.05- 1.2l, 63kw, 86hp CYVA
VW, GOLF VII (5G1, BE1) 1.4 GTE Hybrid 2014.05- 1.4l, 110kw, 150hp CUKB
VW, GOLF VII (5G1, BE1) 1.4 TSI 2014.05- 1.4l, 110kw, 150hp CHPB
VW, GOLF VII (5G1, BE1) 1.4 TSI 2014.05- 1.4l, 92kw, 125hp CPVB
VW, GOLF VII (5G1, BE1) 1.4 TSI 2012.11- 1.4l, 90kw, 122hp CMBA
VW, GOLF VII (5G1, BE1) 1.2 TSI 2012.11- 1.2l, 77kw, 105hp CJZA
VW, GOLF VII (5G1, BE1) 1.2 TSI 2014.04- 1.2l, 81kw, 110hp CYVB
VW, GOLF VII (5G1, BE1) 1.4 TSI 2012.11- 1.4l, 103kw, 140hp CPTA
VW, GOLF VII (5G1, BE1) 1.2 TSI 2012.08- 1.2l, 63kw, 86hp CJZB
VW, GOLF VII (5G1, BE1) 1.4 TGI CNG 2013.06- 1.4l, 81kw, 110hp CPWA
VW, GOLF VII (5G1, BE1) 1.4 TSI MultiFuel 2013.04- 1.4l, 90kw, 122hp CPVA
VW, GOLF VII Estate (BA5) 1.4 TSI 2013.05- 1.4l, 90kw, 122hp CXSA
VW, GOLF VII Estate (BA5) 1.4 TSI MultiFuel 2014.05- 1.4l, 92kw, 125hp CPVB
VW, GOLF VII Estate (BA5) 1.4 TSI 2013.05- 1.4l, 103kw, 140hp CHPA
VW, GOLF VII Estate (BA5) 1.2 TSI 2013.05- 1.2l, 77kw, 105hp CJZA
VW, GOLF VII Estate (BA5) 1.2 TSI 2013.05- 1.2l, 63kw, 86hp CJZB
VW, GOLF VII Estate (BA5) 1.4 TSI 2014.05- 1.4l, 110kw, 150hp CHPB
VW, GOLF VII Estate (BA5) 1.4 TSI 2014.05- 1.4l, 92kw, 125hp CPVB
VW, GOLF VII Estate (BA5) 1.2 TSI 2014.04- 1.2l, 81kw, 110hp CYVB
VW, GOLF VII Estate (BA5) 1.4 TGI CNG 2013.09- 1.4l, 81kw, 110hp CPWA
VW, JETTA IV (162, 163) 1.4 TSI Hybrid 2011.04- 1.4l, 110kw, 150hp CNLA
VW, POLO (6R, 6C) 1.0 TSI 2014.11- 1.0l, 81kw, 110hp CHZC
VW, POLO (6R, 6C) 1.0 TSI 2014.11- 1.0l, 70kw, 95hp CHZB
VW, POLO (6R, 6C) 1.0 2014.01- 1.0l, 44kw, 60hp CHYA
VW, POLO (6R, 6C) 1.4 TSI 2014.05- 1.4l, 110kw, 150hp CZEA
VW, POLO (6R, 6C) 1.2 TSI 2014.01- 1.2l, 81kw, 110hp CJZD
VW, POLO (6R, 6C) 1.4 TSI 2012.10- 1.4l, 103kw, 140hp CPTA
VW, POLO (6R, 6C) 1.0 2014.01- 1.0l, 55kw, 75hp CHYB
VW, UP 1.0 2014.01- 1.0l, 56kw, 75hp
VW, UP 1.0 2011.08- 1.0l, 55kw, 75hp CHYB
VW, UP 1.0 EcoFuel 2012.11- 1.0l, 50kw, 68hp CPGA
VW, UP 1.0 2011.08- 1.0l, 44kw, 60hp CHYA
PACKAGE & DELIVERY
PACKAGE POLY BAG&BRO BRANDED BOX OR CUSTOMIZED BOX IS AVAILABLE
PORT NINGBO/SHANGHAI
LOCATION RUIAN
PRODUCTION LEAD TIME 30DAYS AFTER COMFIRM
